Series UV printing on wine bottles, cups, thermos flasks, metal tubes or any other type of cylinder.
DL 2724
DL 2724
DL2724 is a multi-part rotary printer with the printing speed of a flatbed printer. It is specially designed to personalise all types of cylindrical products.
With its modular configurations, it is perfectly suited to the requirements of industrial production and various production volumes.
- Print a large number of products simultaneously, provided they are of the same height
- Adjustable fixtures to suit part diameter
- Customisable number of printing lines and stations
The ideal combination of high-definition production of medium-sized series and budget control.
Technical specifications
| Min/max object diameter | From 10 to 80 mm Fixing can be customised to suit the diameter of the object |
| Object type | Cylindrical |
| Material type | All types of materials |
| Type of tank | Continuous ink supply / 2000 ml ink tank / secondary tank at constant temperature and pressure / automatic white agitator |
| Number of printheads | 1 to 9 Ricoh G5i printheads Can be customised |
| Resolution | 600*1800dpi / 600*2400dpi / 600*3600dpi / 600*4800dpi |
| Image format | PDF, TIFF, JPEG, EPS, BMP |
| Operating environment | Temperature: 20°C - 30°C / Humidity: 40 - 70 % |
| Energie | AC230V (+- 10%) ; 50 Hz ; P = 8 000 W |
| Dimensions | 4805 x 1775 x 1450 mm |
| Weight | 1600 Kg |
Print speed
Configuration
| 4 rows of white and color uni-direct printing | 168 pcs / hour Full print 36min | 290 pcs / hour Full print 23 min | 560 pcs / hour Full print 12 min |
| 4 rows of white and color bi-direct printing | 373 pcs / hour Full print 18 min | 610 pcs / hour Full print 11 min | 1120 pcs / hour Full print 6 min |
Printing mode : 3 PASS production mode (600dpi*1800dpi)
Printing cylinder material size : diameter 20 mm - width 70 mm
