UV flatbed with a printing area of 1 x 1.6 m.
DL 1016
DL 1016
The DL 1016 is a UV flatbed printer ideal for printing on a variety of substrates. Whether you're printing on rigid or flexible media, it guarantees crisp, long-lasting prints.
With a print area of 1 metre by 1.6 metres, its compact size makes it ideal for workshops or small workspaces.
Its customisable print height of up to 300 mm offers greater flexibility for printing on objects of different thicknesses, from flat substrates to larger parts.
The scanner option detects the position of objects placed randomly on the printing plate and then adapts the images to be printed according to the orientation of each object.
Technical specifications
| Print surface | 1000 x 1600 mm |
| Z height | 0 - 300 mm |
| Type of axis | Magnetic linear axis |
| Material type | Any type of support |
| Type of ink | UV-based : White, CMYK, LC, LM, Varnish + Support for multiple colour combinations |
| Type of tank | Continuous ink supply / Volume: 2000 ml / intelligent ink agitation |
| Number of printheads | 2 to 8 Ricoh G5 / G6 printheads |
| Resolution | 720*900 dpi / 720*1200 dpi / 720*1800 dpi |
| Image format | PDF, TIFF, JPEG, EPS, BMP |
| Operating environment | Temperature: 20 - 30°C / Humidity: 40 - 70 % |
| Dimensions | 2730 x 2577 x 1350 mm |
| Weight | 900 Kg |
| Options | Rotation, Scanner, Anti-static bar, Immaterial barrier, Z height, Caldera |
